November 28, 2024
Calling REST API From SQL Server Stored Procedure
Besides the usual way of calling API from Website or Application, we can call API from SQL Server Stored Process. In this post, I would like to introduce how to call an API from a SQL Server stored procedure by a few steps.
SQL Server doesn't have built-in functionality to directly make HTTP requests, so you'll typically use SQL Server's sp_OACreate and related procedures to interact with COM objects for HTTP requests.
Example using sp_OACreate
Here's a simplified example of how you might use sp_OACreate to call an API from a stored procedure. Please note that this approach relies on the SQL Server's ability to interact with COM objects and may be limited or require additional configuration.
Steps:
1. Enable OLE Automation Procedures:
Before using sp_OACreate, you need to make sure that OLE Automation Procedures are enabled on your SQL Server instance.
EXEC sp_configure 'show advanced options', 1;
RECONFIGURE;
EXEC sp_configure 'ole automation procedures', 1;
RECONFIGURE;
2. Create the Stored Procedure
Here's an example stored procedure that performs a simple HTTP GET request to an API endpoint.
CREATE PROCEDURE CallApiExampleASBEGINDECLARE @object INT;DECLARE @responseText VARCHAR(5000); -- Shoudn't use VARCHAR(MAX)DECLARE @url VARCHAR(255) = 'https://northwind.vercel.app/api/categories'; -- Replace with your API URLDECLARE @status INT;-- Create the XMLHTTP objectEXEC sp_OACreate 'MSXML2.XMLHTTP', @object OUTPUT;-- Open the HTTP connectionEXEC sp_OAMethod @object, 'open', NULL, 'GET', @url, 'false';-- Send the requestEXEC sp_OAMethod @object, 'send';-- Get the response textEXEC sp_OAMethod @object, 'responseText', @responseText OUTPUT;-- Check the statusEXEC sp_OAMethod @object, 'status', @status OUTPUT;-- Get the response textIF((SELECT @ResponseText) <> '')BEGINDECLARE @json NVARCHAR(MAX) = (Select @ResponseText)PRINT 'Response: ' + @json;SELECT *FROM OPENJSON(@json) WITH (id INTEGER '$.id',description NVARCHAR(MAX) '$.description',name NVARCHAR(MAX) '$.name' );ENDELSEBEGINDECLARE @ErroMsg NVARCHAR(30) = 'No data found.';PRINT @ErroMsg;END-- Clean upEXEC sp_OADestroy @object;END;
3. Execute the Stored Procedure
Run the stored procedure to see the output:
EXEC CallApiExample;
Result from API:

Result after executing the stored procedure:

Detailed Explanation:
sp_OACreate: This procedure creates an instance of a COM object. Here, 'MSXML2.XMLHTTP' is used to create an object that can make HTTP requests.
sp_OAMethod: This procedure calls methods on the COM object. In this example:
'open' sets up the request method and URL.
'send' sends the HTTP request.
'responseText' retrieves the response body.
'status' retrieves the HTTP status code.
sp_OADestroy: This procedure cleans up and releases the COM object.
Considerations:
- Security: Using OLE Automation Procedures can pose security risks. Ensure your SQL Server instance is properly secured and consider using more secure methods if available.
- Error Handling: The example doesn't include detailed error handling. In production code, you should handle potential errors from HTTP requests and COM operations.
- Performance: Making HTTP requests synchronously from SQL Server can impact performance and scalability.
- SQL Server Versions: OLE Automation Procedures are supported in many versions of SQL Server but may be deprecated or not available in future versions. So, please check your version's documentation for specifics.
References:
https://learn.microsoft.com/en-us/sql/relational-databases/system-stored-procedures/ole-automation-stored-procedures-transact-sql?view=sql-server-ver16
https://stackoverflow.com/questions/22067593/calling-an-api-from-sql-server-stored-procedure
https://blog.dreamfactory.com/stored-procedures-data-integration-resty-performance/
https://mssqlserver.dev/making-rest-api-call-from-sql-server
